Product Desprtion:

UL 3321 Hook up wire-150°C  600V Xipe Insulation wire

* Rated temperture:105°C

* Rated Voltage:600V

*Refference Standard:UL 758,UL1581, CSA C22.2 NO.2102

*Solid or standed, tinned or bare copper conductor 30-750kcmil

*Cross-limkedpolyolefin insulated wire

*Passes UL VE-1,CSAFT1 vertical flame test

*Uniform insulation thinckness to ensure easy stripping and cutting

*  Enviromental testing pass ROHS, REACH

*Internal wiring of appliances or electronic equipment

NO. SPEICIFICATION DESCRIPTION QUANTITY PRICES BASKET
SFA52021-2601 AWG:26

Conductor No./mm: 7/0.16

Conductor Outer Dia/mm: 0.48

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm: 2		 Color: Red Sign In or Join Free
SFA52021-2602 AWG:26

Conductor No./mm: 7/0.16

Conductor Outer Dia/mm: 0.48

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm: 2		 Color: Black Sign In or Join Free
SFA52021-2603 AWG:26

Conductor No./mm: 7/0.16

Conductor Outer Dia/mm: 0.48

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm: 2		 Color: Blue Sign In or Join Free
SFA52021-2604 AWG:26

Conductor No./mm: 7/0.16

Conductor Outer Dia/mm: 0.48

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm: 2		 Color: White Sign In or Join Free
SFA52021-2605 AWG:26

Conductor No./mm: 7/0.16

Conductor Outer Dia/mm: 0.48

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm: 2		 Color: Yellow Sign In or Join Free
SFA52021-2606 AWG:26

Conductor No./mm: 7/0.16

Conductor Outer Dia/mm: 0.48

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm: 2		 Color: Orange Sign In or Join Free
SFA52021-2607 AWG:26

Conductor No./mm: 7/0.16

Conductor Outer Dia/mm: 0.48

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm: 2		 Color: Green Sign In or Join Free
SFA52021-2401 AWG:24

Conductor No./mm: 11/0.16

Conductor Outer Dia/mm: 0.61

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.15		 Color: Red Sign In or Join Free
SFA52021-2402 AWG:24

Conductor No./mm: 11/0.16

Conductor Outer Dia/mm: 0.61

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.15		 Color: Black Sign In or Join Free
SFA52021-2403 AWG:24

Conductor No./mm: 11/0.16

Conductor Outer Dia/mm: 0.61

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.15		 Color: Blue Sign In or Join Free
SFA52021-2404 AWG:24

Conductor No./mm: 11/0.16

Conductor Outer Dia/mm: 0.61

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.15		 Color: White Sign In or Join Free
SFA52021-2405 AWG:24

Conductor No./mm: 11/0.16

Conductor Outer Dia/mm: 0.61

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.15		 Color: Yellow Sign In or Join Free
SFA52021-2406 AWG:24

Conductor No./mm: 11/0.16

Conductor Outer Dia/mm: 0.61

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.15		 Color: Orange Sign In or Join Free
SFA52021-2407 AWG:24

Conductor No./mm: 11/0.16

Conductor Outer Dia/mm: 0.61

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.15		 Color: Green Sign In or Join Free
SFA52021-2201 AWG:22

Conductor No./mm: 17/0.16

Conductor Outer Dia/mm: 0.76

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.4		 Color: Red Sign In or Join Free
SFA52021-2202 AWG:22

Conductor No./mm: 17/0.16

Conductor Outer Dia/mm: 0.76

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.4		 Color: Black Sign In or Join Free
SFA52021-2203 AWG:22

Conductor No./mm: 17/0.16

Conductor Outer Dia/mm: 0.76

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.4		 Color: Blue Sign In or Join Free
SFA52021-2204 AWG:22

Conductor No./mm: 17/0.16

Conductor Outer Dia/mm: 0.76

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.4		 Color: White Sign In or Join Free
SFA52021-2205 AWG:22

Conductor No./mm: 17/0.16

Conductor Outer Dia/mm: 0.76

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.4		 Color: Yellow Sign In or Join Free
SFA52021-2206 AWG:22

Conductor No./mm: 17/0.16

Conductor Outer Dia/mm: 0.76

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.4		 Color: Orange Sign In or Join Free
SFA52021-2207 AWG:22

Conductor No./mm: 17/0.16

Conductor Outer Dia/mm: 0.76

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.4		 Color: Green Sign In or Join Free
SFA52021-2001 AWG:20

Conductor No./mm: 21/0.178

Conductor Outer Dia/mm: 0.94

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.6		 Color: Red Sign In or Join Free
SFA52021-2002 AWG:20

Conductor No./mm: 21/0.178

Conductor Outer Dia/mm: 0.94

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.6		 Color: Black Sign In or Join Free
SFA52021-2003 AWG:20

Conductor No./mm: 21/0.178

Conductor Outer Dia/mm: 0.94

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.6		 Color: Blue Sign In or Join Free
SFA52021-2004 AWG:20

Conductor No./mm: 21/0.178

Conductor Outer Dia/mm: 0.94

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.6		 Color: White Sign In or Join Free
SFA52021-2005 AWG:20

Conductor No./mm: 21/0.178

Conductor Outer Dia/mm: 0.94

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.6		 Color: Yellow Sign In or Join Free
SFA52021-2006 AWG:20

Conductor No./mm: 21/0.178

Conductor Outer Dia/mm: 0.94

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.6		 Color: Orange Sign In or Join Free
SFA52021-2007 AWG:20

Conductor No./mm: 21/0.178

Conductor Outer Dia/mm: 0.94

Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.6		 Color: Green Sign In or Join Free
SFA52021-1801 AWG:18

Conductor No./mm: 16/0.254

Conductor Outer Dia/mm: 1.16
Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.8		 Color: Red Sign In or Join Free
SFA52021-1802 AWG:18

Conductor No./mm: 16/0.254

Conductor Outer Dia/mm: 1.16
Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.8		 Color: Black Sign In or Join Free
SFA52021-1803 AWG:18

Conductor No./mm: 16/0.254

Conductor Outer Dia/mm: 1.16
Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.8		 Color: Blue Sign In or Join Free
SFA52021-1804 AWG:18

Conductor No./mm: 16/0.254

Conductor Outer Dia/mm: 1.16
Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.8		 Color: White Sign In or Join Free
SFA52021-1805 AWG:18

Conductor No./mm: 16/0.254

Conductor Outer Dia/mm: 1.16
Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.8		 Color: Yellow Sign In or Join Free
SFA52021-1806 AWG:18

Conductor No./mm: 16/0.254

Conductor Outer Dia/mm: 1.16
Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.8		 Color: Orange Sign In or Join Free
SFA52021-1807 AWG:18

Conductor No./mm: 16/0.254

Conductor Outer Dia/mm: 1.16
Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:2.8		 Color: Green Sign In or Join Free
SFA52021-1601 AWG:16

Conductor No./mm: 26/0.254

Conductor Outer Dia/mm: 1.49
Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:3.1		 Color: Red Sign In or Join Free
SFA52021-1602 AWG:16

Conductor No./mm: 26/0.254

Conductor Outer Dia/mm: 1.49
Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:3.1		 Color: Black Sign In or Join Free
SFA52021-1603 AWG:16

Conductor No./mm: 26/0.254

Conductor Outer Dia/mm: 1.49
Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:3.1		 Color: Blue Sign In or Join Free
SFA52021-1604 AWG:16

Conductor No./mm: 26/0.254

Conductor Outer Dia/mm: 1.49
Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:3.1		 Color: White Sign In or Join Free
SFA52021-1605 AWG:16

Conductor No./mm: 26/0.254

Conductor Outer Dia/mm: 1.49
Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:3.1		 Color: Yellow Sign In or Join Free
SFA52021-1606 AWG:16

Conductor No./mm: 26/0.254

Conductor Outer Dia/mm: 1.49
Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:3.1		 Color: Orange Sign In or Join Free
SFA52021-1607 AWG:16

Conductor No./mm: 26/0.254

Conductor Outer Dia/mm: 1.49
Insulation Thickness /mm :0.76

Insulation Outer Dia/mm:3.1		 Color: Green Sign In or Join Free
